Ingested single-walled carbon nanotubes affect on immunological, hematological and microecological indices of Wistar rats

Мұқаба

Дәйексөз келтіру

Толық мәтін

Аннотация

Introduction. Single-walled carbon nanotubes (SWCNTs) can create risks to human health when they enter the body by oral route when used in packaging materials, as promising agrochemicals and pesticides.

The aim of the study. Evaluation of the subacute oral toxicity of SWCNT in rats.

Material and methods. In the 92-days of the experiment, the SWCNTs were administered to rats along with drinking water at doses of 0 (control); 0.01; 0.1; 1.0 and 10 mg/kg body weight (BW) in the groups 1-5, respectively. Hematological indices of blood, apoptosis of hepatocytes, levels of pro- and anti-inflammatory cytokines in blood plasma and their production by cells of the spleen ex vivo, the content of the main and transient components of the intestinal microbiocenosis in the cecum were studied. There were determined hematological blood counts, hepatocyte apoptosis, levels of pro- and anti-inflammatory cytokines in blood plasma and their production by spleen cells ex vivo, content in the cecum of the main and transient components of the intestinal microbiocenosis.

Results. At the SWCNT dose of 0.01 mg/kg BW there was a decrease in the number of neutrophils and basophils, an increase in the number of lymphocytes, and a decrease in the number and volume of platelets. At a dose of 0.1 mg/kg bw there was noted a decrease in the number of cells in the early stage of apoptosis and the total number of cells in apoptosis, as well as a significant decrease in the levels of cytokines IL-10, IL-2, IL-4, IL-13, chemokine MIP-3a, TGF-β isoform 1; at a dose of 1.0 mg/kg IL-12p70, and TGF-β isoforms 1 and 3. TGF- β2 level was significantly elevated in group 5. The suppressive effect was noted for SWCNTs on the mold flora in intestinal contents at all doses of nanomaterial used, whereas the number of yeasts increased at 1 mg/kg BW. The immunization of rats with ovalbumin had a clear modulating effect on the immunotropic effects of SWCNTs administered at a dose of 0.1 mg/kg BW in a 28-days experiment.

Discussion. The mechanisms of the observed changes development are likely to be associated with both systemic anti-inflammatory effects and with a decrease in the effect of SWCNT on the permeability of the intestinal barrier to protein antigens and microbial toxins.

Conclusion. SWCNTs exhibit a number of effects in relation to the studied indices that do not demonstrate a monotonic dependence on the dose of nanomaterial, which, apparently, is related to the processes of aggregation of the SWCNT.

Авторлар туралы

V. Shipelin

Federal Research Centre for Nutrition and Biotechnology

Хат алмасуға жауапты Автор.
Email: noemail@neicon.ru
ORCID iD: 0000-0002-0015-8735
Ресей

N. Riger

Federal Research Centre for Nutrition and Biotechnology

Email: noemail@neicon.ru
ORCID iD: 0000-0001-7149-2485
Ресей

E. Trushina

Federal Research Centre for Nutrition and Biotechnology

Email: noemail@neicon.ru
ORCID iD: 0000-0002-0035-3629
Ресей

O. Mustafina

Federal Research Centre for Nutrition and Biotechnology

Email: noemail@neicon.ru
ORCID iD: 0000-0001-7231-9377
Ресей

Yu. Markova

Federal Research Centre for Nutrition and Biotechnology

Email: noemail@neicon.ru
ORCID iD: 0000-0002-2631-6412
Ресей

A. Polyanina

Federal Research Centre for Nutrition and Biotechnology

Email: noemail@neicon.ru
ORCID iD: 0000-0002-2766-7716
Ресей

A. Masyutin

M.V. Lomonosov Moscow State University

Email: noemail@neicon.ru
Ресей

A. Chernov

A.M. Prokhorov General Physics Institute

Email: noemail@neicon.ru
ORCID iD: 0000-0002-6492-9068
Ресей

Ivan Gmoshinsky

Federal Research Centre for Nutrition and Biotechnology

Email: gmosh@ion.ru
ORCID iD: 0000-0002-3671-6508

MD, Ph.D. DSci., a leading researcher of the Department of Food Toxicology and Evaluation of Nanotechnology Safety of the Federal Research Centre for Nutrition and Biotechnology, Moscow, 109240, Russian Federation.

e-mail: gmosh@ion.ru

Ресей

S. Khotimchenko

Federal Research Centre for Nutrition and Biotechnology; I.M. Sechenov First Moscow State Medical University

Email: noemail@neicon.ru
ORCID iD: 0000-0002-5340-9649
Ресей

Әдебиет тізімі

  1. De Volder M.F., Tawfick S.H., Baughman R.H., Hart A.J. Carbon nanotubes: present and future commercial applications. Science. 2013; 339(6119): 535-9. https://doi.org/10.1126/science.1222453
  2. Coyuco J.C., Liu Y., Tan B.-J., Chiu G.N.C. Functionalized carbon nanomaterials: exploring the interactions with Caco-2 cells for potential oral drug delivery. Int. J. Nanomedicine. 2011; 6: 2253-63. https://doi.org/10.2147/IJN.S23962
  3. Monaco A.M., Giugliano M., Beilstein J. Nanotechnol. 2014; 5: 1849-1863. https://doi.org/10.3762/bjnano.5.19
  4. Martínez-Ballesta M.C., Zapata L., Chalbi N., Carvajal M. Multiwalled carbon nanotubes enter broccoli cells enhancing growth and water uptake of plants exposed to salinity. J. Nanobio-technology. 2016; 14: 42.
  5. Vasyukova I.A., Gribanovskii S.L., Gusev A.A., Ubogov A.Yu., Khaliullin T.O., Fatkhutdinova L.M. et al. Assessment of reproductive toxicity of multiwalled carbon nanotubes and their putative effects on population ecology of mouselike rodents. Nanotechnol. Russ. 2015; 10(5-6): 458-67.
  6. Shvedova A.A., Kisin E.R., Mercer R., Murray A.R., Johnson V.J., Potapovich A.I. et al. Unusual inflammatory and fibrogenic pulmonary responses to single-walled carbon nanotubes in mice. Am. J. Physiol. Lung Cell. Mol. Physiol. 2005; 289(5): 698-708. https://doi.org/10.1152/ajplung.00084.2005
  7. Kobayashi N., Izumi H., Morimoto Y. Review of toxicity studies of carbon nanotubes. J. of Occup. Health. 2017; 59(5): 394-407.
  8. Li J., Li L., Chen H., Chang Q., Liu X., Wu Y. et al. Application of vitamin E to antagonize SWCNTs-induced exacerbation of allergic asthma. Sci. Rep. 2014; 4: 4275. https://doi.org/10.1038/srep04275
  9. Park E.J., Choi J., Kim J.H., Lee B.S., Yoon C., Jeong U. et al. Subchronic immunotoxicity and screening of reproductive toxicity and developmental immunotoxicity following single instillation of HIPCO-single-walled carbon nanotubes: purity-based comparison. Nanotoxicology. 2016; 10(8): 1188-1202. https://doi.org/10.1080/17435390.2016.1202348
  10. Madani S.Y., Mandel A., Seifalian A.M. A concise review of carbon nanotube’s toxicology. Nano Reviews. 2013; 4: 21521. https://doi.org/10.3402/nano.v4i0.21521
  11. Kolosnjaj-Tabi J., Hartman K.B., Boudjemaa S., Ananta J.S., Morgant G., Szwarc H. et al. In vivo behavior of large doses of ultrashort and full-length single-walled carbon nanotubes after oral and intraperitoneal administration to Swiss mice. ACS Nano. 2010; 4(3): 1481-92. https://doi.org/10.1021/nn901573w
  12. Campagnolo L., Massimiani M., Palmieri G., Bernardini R., Sacchetti C., Bergamaschi A. et al. Biodistribution and toxicity of pegylated single wall carbon nanotubes in pregnant mice. Part. and Fibre Toxicol. 2013; 10: 21. https://doi.org/10.1186/1743-8977-10-21
  13. Khripach L.V., Rakhmanin Yu.A., Mikhailova R.I., Knyazeva T.D., Koganova Z.I., Zheleznyak E.V. et al. Biochemical effects of chronic peroral administration of carbon nanotubes and activatyed charcoal in drinking water in rats. Gigiena i sanitariya. 2014; 5: 36-42 (in Russian)
  14. Allegri M., Perivoliotis D.K., Bianchi M.G., Chiu M., Pagliaro A., Koklioti M.A. et al. Toxicity determinants of multi-walled carbon nanotubes: The relationship between functionalization and agglomeration. Toxicol. Rep. 2016; 3: 230-243. https://doi.org/10.1016/j.toxrep.2016.01.011
  15. Shipelin V.A., Shumakova A.A., Masyutin A.G., Chernov A.I., Sidorova Yu.S., Gmoshinski I.V. et al. In vivo subacute oral toxicity assessment of multiwalled carbon nanotubes: characteristic of nanomaterial and integral indicators. Nanotech. Russ. 2017; 12(9-10): 559-68. https://doi.org/10.1134/S199507801705010X
  16. Raspopov R.V., Trushina E.N., Gmoshinsky I.V., Khotimchenko S.A. Bioavailability of nanoparticles of ferric oxide when used in nutrition. Experimental results in rats. Voprosy pitaniya. 2011; 80(3): 25-30 (in Russian).
  17. Lymphocytes. A practical approach. Ed. by Klaus G.G.B. Oxford, Washington D.C.: IRI Press. 1987, 395 p.
  18. Jin H., Heller D.A., Sharma R., Strano M.S. Size-dependent cellular uptake and expulsion of single-walled carbon nanotubes: single particle tracking and a generic uptake model for nanoparticles. ACS Nano. 2009; 3(1): 149-58. https://doi.org/10.1021/nn800532m
  19. Li P., Lai X., Frank A., Witzmann F.A., Blazer-Yost B.L. Bioinformatic Analysis of Differential Protein Expression in Calu-3 Cells Exposed to Carbon Nanotubes. Proteomes. 2013; 1(3): 219-39. https://doi.org/10.3390/proteomes1030219
  20. Chen H., Zhao R., Wang B., Zheng L., Ouyang H., Wang H. et al. Acute oral administration of single-walled carbon nanotubes increases intestinal permeability and inflammatory responses: association with the changes in gut microbiota in mice. Adv. Healthc. Mater. 2018. https://doi.org/10.1002/adhm.201701313
  21. Polimeni M., Gulino G.R., Gazzano E., Kopecka J., Marucco A., Fenoglio I. et al. Multi-walled carbon nanotubes directly induce epithelial-mesenchymal transition in human bronchial epithelial cells via the TGF-β-mediated Akt/GSK-3β/SNAIL-1 signalling pathway. Part. Fibre Toxicol. 2015; 13(1): 27. https://doi.org/10.1186/s12989-016-0138-4
  22. Azad N., Iyer A.K., Wang L., Liu Y., Lu Y., Rojanasakul Y. Reactive oxygen species-mediated p38 MAPK regulates carbon nanotube-induced fibrogenic and angiogenic responses. Nanotoxicology. 2013; 7(2): 157- 68. https://doi.org/10.3109/17435390.2011.647929
  23. Amruta M., Luanpitpong S., Dong C., Wang L., He X., Battelli L. et al. Effect of fiber length on carbon nanotube-induced fibrogenesis. Int. J. Mol. Sci. 2014; 15(5): 7444-61. https://doi.org/10.3390/ijms15057444
  24. Albini A., Pagani A., Pulze L., Antonino B., Principi E., Congiu T. et al. Environmental im-pact of multi-wall carbon nanotubes in a novel model of exposure: systemic distribution, macrophage accumulation, and amyloid deposition. Int. J. Nanomedicine. 2015; 10: 6133-45. https://doi.org/10.2147/IJN.S85275
  25. Shipkowski K.A., Taylor A.J., Thompson E.A., Glista-Baker E.E., Sayers B.C., Messenger Z.J. et al. an allergic lung microenvironment suppresses carbon nanotube-induced inflammasome activation via STAT6-dependent inhibition of caspase-1. PLoS One, 2015; 10(6): e0128888. https://doi.org/10.1371/journal.pone.0128888
  26. Batishcheva S.Yu., Kuznetsova G.G., Bykova I.B., Efimochkina N.R., Sheveleva S.A. Influence of molds consumed with food on intestinal microflora in rats. Voprosy pitaniya. 2009; 78(2): C.43-47 (in Russian).
  27. Sheveleva S.A., Gmoshinski I.V., Boltyanskaya E.V., Efimochkina N.R., Zorin S.N., Mazo V.K. The effect of mold spores consumed with food on the course of systemic anaphylaxis in rats. Voprosy pitaniya. 2004; 73(6): 43-47 (in Russian).
  28. Kang S., Mauter M.S., Elimelech M. Microbial cytotoxicity of carbon-based nanomaterials: implications for river water and wastewater effluent. Environ Sci. Technol. 2009; 43(7): 2648-53.
  29. Bhattacharya K., Andón F.T., El-Sayed R., Fadeel B. Mechanisms of carbon nanotube-induced toxicity: focus on pulmonary inflammation. Adv. Drug. Deliv. Rev. 2013; 65(15): 2087-97. https://doi.org/10.1016/j.addr.2013.05.012
  30. Park E.J., Cho W.S., Jeong J., Yi J., Choi K., Park K. Pro-inflammatory and potential allergic responses resulting from B cell activation in mice treated with multi-walled carbon nanotubes by intratracheal instillation. Toxicology. 2009; 259(3): 113-21. https://doi.org/10.1016/j.tox.2009.02.009
