A cytological study of imprint smears (touch preparation cytology) to evaluate the toxicity of metal-containing nanoparticles in experimental animals

Cover Page

Cite item

Full Text

Abstract

Introduction. Touch preparation cytology is a well-known technique widely used in clinical practice. It can be also applied for an express assessment of cyto-morphological effects of metal-containing nanoparticles in experimental animals.

Material and methods. We’ve studied 144 imprint smears (of the liver, kidneys, lungs, tracheobronchial and mesenteric lymph nodes) taken from 52 rats, weighed 280-300 g, aged 3.5 months. This was done following a subchronic intraperitoneal administration of TiO2, Al2O3, and SiO2 nanoparticles, in a range of doses, and a subacute (5-times) inhalational exposure to 1 mg/m3 NiO NPs. Leishman stain was used. Cytological markers were studied at х100/х1000 magnification, using a Carl Zeiss Primo Star microscope, with a USCMOS camera for visualization. The count was done for every 200 cells of lung, liver and kidney specimens and for every 100 cells of lymph node tissue. The differences between the group means (in case of quantitative results) were analyzed using a Student’s t-test. The differences between the group means were considered statistically significant if the probability of those differences being accidental didn’t exceed 5% (р < 0,05).

Results. We report the principal results obtained in a cytological study of imprint smears (touch preparations) of rat organs following the exposure to metal-containing nanoparticles. The main types of cellular responses were determined. Degenerative and dystrophic changes were observed in touch preparations of the liver, kidneys, and lungs following administration of nanoparticles in a range of doses and by various routes of exposure. Hyperergic inflammatory responses were seen upon the exposure to nickel oxide nanoparticles. A local cellular immune response was observed as an increase of macrophage percentage in imprint smears of some organs.

Conclusion. The use of touch preparation cytology together with histological examination of tissue specimens expand opportunities for a more relevant morphological and quantitative analysis when studying the toxic effects of metal-containing nanoparticles.

About the authors

R. R. Sakhautdinova

Yekaterinburg Medical Research Center for Prophylaxis and Health Protection in Industrial Workers, Russian Agency for Consumer Rights Protection

Author for correspondence.
Email: noemail@neicon.ru
ORCID iD: 0000-0002-2726-9259
Russian Federation

M. P. Sutunkova

Yekaterinburg Medical Research Center for Prophylaxis and Health Protection in Industrial Workers, Russian Agency for Consumer Rights Protection

Email: noemail@neicon.ru
ORCID iD: 0000-0002-1743-7642
Russian Federation

I. A. Minigalieva

Yekaterinburg Medical Research Center for Prophylaxis and Health Protection in Industrial Workers, Russian Agency for Consumer Rights Protection

Email: noemail@neicon.ru
ORCID iD: 0000-0002-0097-7845
Russian Federation

Tatyana V. Bushueva

Yekaterinburg Medical Research Center for Prophylaxis and Health Protection in Industrial Workers, Russian Agency for Consumer Rights Protection

Email: bushueva@ymrc.ru
ORCID iD: 0000-0002-5872-2001

MD, Ph.D., Head of Laboratory Diagnostics Department, Yekaterinburg Medical Research Center for Prophylaxis and Health Protection in Industrial Workers, Russian Agency for Consumer Rights Protection, Yekaterinburg, 620014, Russian Federation.

e-mail: bushueva@ymrc.ru

Russian Federation

References

  1. Glushkova A.V., Radilov A.S., Dulov S.A. Features of manifestation of nanoparticles toxicity. Gigiena i sanitariya [Hygiene and Sanitation, Russian journal]. 2011; (2): 81–6. (in Russian)
  2. Minigalieva I.A., Bushueva T.V., Fröhlich E., Meindl C., Panov V.G., Varaksin A.N. et al. Are in vivo and in vitro assessments of comparative and combined toxicity of the same metallic nanoparticles compatible, or contradictory, or both? A juxtaposition of data obtained in some experiments with NiO and Mn3O4 nanoparticles. Food Chem Toxicol. 2017; 109 (1): 393–404. https://doi.org/10.1016/j.fct.2017.09.032
  3. Dekkers S., Ma-Hock L., Lynch I., Russ M., Miller M.R., Schins R.P.F. et al. Differences in the toxicity of cerium dioxide nanomaterials after inhalation can be explained by lung deposition, animal species and nanoforms. Inhal Toxicol. 2018; 4: 1–14. https://doi.org/10.1080/08958378.2018.1516834
  4. Bazeluk L.Т., Duzbaeva N.М., Khanturina G.R. Temirtau Dust Chronic Exposure on Experimental Animals. European Researcher. 2013; 6 (1): 1618–23.
  5. Gonohova M.N., Bojko T.V., El’cova A.A. Comparative cytomorphological characteristics of rat spleen exposed by pesticides. Sovremennyye problemy nauki i obrazovaniya. 2013; (6): 1056. (in Russian)
  6. Dosynbaeva G.N. Cytomorphological assessment of bronchoalveolar lavage cells, liver and stomach when exposed to cotton dust, containing a organophosphorus pesticides in the experiment. International Scientific and Practical Conference. 2016; 3 (5): 22–30. (in Russian)
  7. Kruglikov G.G., Suslov V.B. Features of the cell’s functional morphology on imprints of organs, film preparations of connective tissue and blood smears. Mediko-biologicheskiye problemy. 2014; 4: 86–92.
  8. Abramov M.G. Clinical cytology [Klinicheskaya tsitologiya. Izd. 2, ispr. i dop.]. Moscow: Meditsina; 1974. 336 p. (in Russian)
  9. Bibbo M., Wilbur D. Comprehensive cytopathology. Saunders; 2008. 1136 p.
  10. Tannenbaum M., Madden J.F., eds. Diagnostic atlas of genitourinary pathology. Philadelphia: Churchill Livingstone Elsevier; 2006. 492 p.
  11. Petrova A.S., Ptohova M.P. Guidelines for the cytological diagnosis of human tumors [Rukovodstvo po tsitologicheskoy diagnostike opukholey cheloveka]. Moscow: Meditsina; 1976. (in Russian)
  12. Shabalova I.P. Current opportunities and prospects of clinical cytology. Novosti klinicheskoy tsitologii Rossii. 2014; 1 (1–2): 64. (in Russian)
  13. Thompson D.W. Canadian experience in cytology proficiency testing. Acta Cytol. 1989; 33: 484–6.
  14. Tashke K. Introduction to quantitative cytological histological morphology [Vvedeniye v kolichestvennuyu tsito-gistologicheskuyu morfologiyu]. Bucharest: izd-vo AN SRR; 1980. (in Russian)
  15. Minigalieva I.A., Katsnelson B.A., Privalova L.I., Sutunkova M.P., Gurvich V.B., Bushueva T.V. et al. Сombined subchronic toxicity of aluminum (III), titanium (IV) and silicon (IV) oxide nanoparticles and its alleviation with a complex of bioprotectors. Int J Mol Sci. 2018; 19 (3): 837. https://doi.org/10.3390/ijms19030837
  16. Mil’to I.V., Mihajlov G.A., Rat’kin A.V., Magaeva A.A. The effect of nanosized particles on the morphology of the internal mouse organs during intravenous administration of a nanopowder solution Fe3O4. Byulleten’ sibirskoy meditsiny. 2008; 1: 32–6. (in Russian)
  17. Dumala N., Mangalampalli B., Chinde S., Kumari S., Mahoob M., Rahman M. et al. Genotoxicity study of nickel oxide nanoparticles in female Wistar rats after acute oral exposure. Mutagenesis. 2017; 32 (4): 417–27. https://doi.org/10.1093/mutage/gex007
  18. Oyabu T., Myojo T., Lee B-W., Okada T., Izumi H., Yoshiura Y. et al. Biopersistence of NiO and TiO2 Nanoparticles Following Intratracheal Instillation and Inhalation. Int J Mol Sci. 2017; 18 (12): 2757. https://doi.org/10.3390/ijms18122757
  19. Pilotti S., Rilke F., Alasio L. et al. The role fine needle aspiration in the assessment of renal masses. Acta Cytol. 1988; 32: 1–10.
  20. Van Pelt J.F., Severi T., Crabbe T. et al. Expression of hepatitis C viruscore protein impairs DNA repair in human hepatoma cells. Cancer Lett. 2004; 209: 197–205. https://doi.org/10.1016/j.canlet.2003.11.035
  21. Morrison C., Marsh W., Frankel W.L. A comparison of CD10 to pCEA, MOC-31, and hepatocyte for the Distinction of malignant tumors in the liver. Mod Pathol. 2002; 15: 1279–87.
  22. Yang G.C.H., Yang G.Y., Tao L.C. Cytologic features and histologic correlations of microacinar and microtrabecular types of well-differentiated hepatocellular carcinoma in fine needle aspiration biopsy. Cancer Cytopathol. 2004; 102: 27–33. https://doi.org/10.1002/cncr.20000
  23. Roberts R.A., Ganey P.E., Ju C. et al. Role of the Kupffer cell inmediating hepatic toxicity and carcinogenesis. Toxicol Sci. 2007; 96 (1): 2–15. https://doi.org/10.1093/toxsci/kfl173
  24. Laudadio J., Christiansen L., Mostafa F. et al. The diagnostic utility of the differential cell count of the bronchoalveolar lavage (BAL) fluid in patients with interstitial lung disease. Ca (Ca Cytopath suppl). 2005; 105: 402.
  25. Romagosa C., Morente V., Ramirez J.F. et al. Intranuclear inclusions in fine needle aspirates of bronchial low grade mucoepidermoid carcinoma with clear cell change. A report of two cases. Acta Cytol. 2002; 46: 57–60. https://doi.org/10.1159/000326717
  26. Füezesi L., Höer P.-W., Schmidt W. Exfoliative cytology of multiple endobronchial granular cell tumor. Acta Cytol. 1989; 33: 516–8.
  27. Tsyrkunov V.M., Andreev V.P., Kravchuc R.I., Prokopchic N.I. Clinical cytology of liver: Cupffer`s cells. Journal of the Grodno State Medical University. 2017; 15 (4): 419–31.
  28. Naito M., Hasegawa G., Takahashi K. Development, differentiation, and maturation of Kupffer cells. Microsc Res Tech. 1997; 39 (4): 350–64.
  29. Sutunkova M.P., Solovyeva S.N., Minigalieva I.A., Gurvich V.B., Makeyev O.H., Shur V.Y. et al. Toxic Effects of Low-Level Long-Term Inhalation Exposures of Rats to Nickel Oxide Nanoparticles. Int J Mol Sci. 2019; 20 (7): 1778. https://doi.org/10.3390/ijms20071778
  30. Zigmond E. et al. Infiltrating monocyte-derived macrophages and resident kupffer cells display different ontogeny and functions in acute liver injury. J Immunol. 2014; 193 (1): 344–53. https://doi.org/10.4049/jimmunol.1400574
  31. Shevaldin A.G. Resident liver macrophages and clinical and laboratory parameters in chronic hepatitis C. Aktual’nye voprosy infekcionnoj patologii. Materials of the All-Russian scientific conference of young scientists with international participation. SPbGMU named after Acad. I.P. Pavlov. St. Petersburg, 2009. p. 34.
  32. Elbakidze G.M. Mechanisms of the protective action of Kupffer cells activated by endotoxin on hepatocytes. Vestnik RAMN. 2012; 5: 48–54.
  33. Lyamina S.V., Malyshev I.Yu., Malyshev I.Yu. Macrophage polarization in the modern concept of the immune response formation. Fundamental’nyye issledovaniya. 2014; 10 (5): 930–5.
  34. Lee S., Hwang S-H., Jeong J., Han Y., Kim S.-H., Lee D-K. et al. Nickel oxide nanoparticles can recruit eosinophils in the lungs of rats by the direct release of intracellular eotaxin. Part Fibre Toxicol. 2016; 13: 30. https://doi.org/10.1186/s12989-016-0142-8
  35. Radauer-Preiml I., Andosch A., Hawranek T., Luetz-Meindl U., Wiederstein M., Horejs-Hoeck. J. Nanoparticle-allergen interactions mediate human allergic responses: protein corona characterization and cellular responses. Part Fibre Toxicol. 2016; 13: 3. https://doi.org/10.1186/s12989-016-0113-0
